FT-1000MP Mark V
Источник:
GENERAL
| Type | Amateur HF transceiver |
|---|---|
| Frequency range | TX: 10-160 m + WARC RX: 0.1-30 MHz |
| Tuning steps | 0.625/1.25/2.5/5/10 Hz (for SSB/CW/RTTY)100 Hz (for AM/FM) |
| Frequency stability | ±0.5 ppm @ 25°C (77°F), after 1 minute warmup±0.25 ppm with TCXO-6 option |
| Mode | TX: AM / FM / SSB / CW / RTTY / Packet RX: AM / AM-sync / FM / SSB / CW / RTTY / Packet |
| Channels / memory management | 99 regular 9 PMS 5 QMB RAM storage with lithium battery backup (CR2032) |
| Repeater shift / offset | ±0-200 KHz |
| Power supply | 13.8 and 30 VDC from separate FP-29 PSU (6-pin Molex connector) |
| Current drain / power consumption | RX: Max 2.7 ATX: Max 2.2 A @ 13.8 V and 14.5 A @ 30 V |
| Antenna impedance / connector | 50 ohm (16.5-150 ohm with ATU) / Two SO-239 |
| Dimensions (W*H*D) | 410*135*347 mm (16*5.3*13.7") |
| Weight | 14 Kg (31 lb) |
| Other features | CTCSS/PL. Automatic antenna tuner. VOX. CAT control. Twin RX. DSP |
RECEIVER SECTION
| Receiver system | Triple conversion superheterodyne (FM) 1st IF: 70.455 MHz 2nd IF: 8.215 MHz 3rd IF: 455 KHz Quadruple conversion superheterodyne (AM/SSB/CW) 1st IF: 70.455 MHz 2nd IF: 8.215 MHz 3rd IF: 455 KHz 4th IF: ? |
|---|---|
| Sensitivity | AM (10 dB S/N, 6 KHz BW) 0.5-1.8 MHz: 13 uV 1.8-30 MHz: 2 uV FM (12 dB SINAD) 1.8-30 MHz: 0.5 uV SSB/CW (10 dB S/N, 2.0 KHz BW) 0.5-1.8 MHz: 2 uV 1.8-30 MHz: 0.16 uV |
| Selectivity | Available bandwidths SettingModes-6 dB-60 dB 2.0 KHzAll except FM1.8 KHz3.6 KHz 2.4 KHzAll except FM2.2 KHz4.2 KHz 250 HzCW/RTTY/Packet250 Hz700 Hz 500 HzCW/RTTY/Packet500 Hz1.8 KHz --AM Wide4 KHz14 KHz --FM8 KHz19 KHz |
| Setting | Modes |
| 2.0 KHz | All except FM |
| 2.4 KHz | All except FM |
| 250 Hz | CW/RTTY/Packet |
| 500 Hz | CW/RTTY/Packet |
| -- | AM Wide |
| -- | FM |
| Image rejection | Main RX: 80 dBSub RX: 50 dB |
| AF output power / speaker | 2 W at 10% distortion / 4 ohm |
| External speaker connector | 3.5 mm, 4-8 ohm |
TRANSMITTER SECTION
| RF output power | Max pwr AM:50 W FM:200 W SSB (PEP):200 W CW:200 W |
|---|---|
| AM | 50 W |
| FM | 200 W |
SSB (PEP)
| CW | 200 W |
|---|---|
| Modulation system | AM: Low-level, early stage FM: Variable reactance SSB: Balanced modulation AFSK: Audio frequency shift keying |
| Max FM deviation (Factory set) | ±2.5 KHz |
| Spurious emissions | Better than -60 dB |
| Microphone impedance / connector | 500-600 ohm / 8-pin (Metal locking ring connector) |
| Microphone input level | — |
MISCELLANEOUS
| Manufactured | 2000-2005 (Discontinued) |
|---|---|
| Additional info | — |
| DVS-2 FH-1 LL-7 MD-100A8X MH-31B8 SP-8 TCXO-6 YF-110CN YF-110SN YF-114CN YF-114SN YF-115C YH-77STA | Digital voice recording unit Remote control keypad Phone patch unit. Mounts inside SP-8 Desk microphone Hand microphone External speaker with filters. Phone patch option High stability master reference oscillator. ±0.25 ppm CW narrow filter. 250 Hz. IF: 455 KHz Filter. 2 KHz. IF: 455 KHz Filter. 250 Hz. IF: 8.2 MHz Filter. 2 KHz. IF: 8.2 MHz Collins mechanical CW/RTTY narrow filter. 500 Hz. IF: 455 KHz Lightweight headphones |
