UBC-200XLT
Источник:
GENERAL
| Type | VHF/UHF receiver/scanner |
|---|---|
| Frequency range | 66-88 / 108-174 / 406-512 / 806-956 MHz |
| Tuning steps | — |
| Frequency stability | — |
| Mode | AM/FM |
| Channels / memory management | 200 regular in 20 banks @ 15 channels per second |
| Power supply | 7.2 VDC (NiCd battery pack) or 12 VDC external |
| Current drain / power consumption | — |
| Antenna impedance / connector | 50 ohm / BNC |
| Dimensions (W*H*D) | 70*190*32 mm (2.75*7.5*1.25") |
| Weight | 460 g (1.01 lb), with batteries |
| Other features | Backlit display. |
RECEIVER SECTION
| Receiver system | Double conversion superheterodyne 1st IF: 10.85 MHz 2nd IF: 450 KHz |
|---|---|
| Sensitivity | 0.3-0.8 uV (Depending on band) |
| Selectivity | — |
| Image rejection | — |
| AF output power / speaker | 480 mW at ?% distortion /? ohm |
| External speaker connector | — |
MISCELLANEOUS
| Manufactured | 198x-19xx (Discontinued) |
|---|---|
| Additional info | New price 1988 in Sweden: SEK 3495:- |
| BP-205 | NiCd battery pack. 7.2 V, 600 mAh |
