SDS-200
Источник:
GENERAL
| Type | HF/VHF/UHF receiver/scanner |
|---|---|
| Frequency range | USA 25-512 / 758-824 / 849-869 / 895-960 / 1240-1300 MHz |
| Tuning steps | 5 / 6.25 / 7.5 / 8.33 / 10 / 12.5 / 15 / 20 / 25 / 50 / 100 KHz |
| Frequency stability | — |
| Mode | Analog AM / FM / NFM / FMB / WFM DV/Digital APCO P25 I/II DMR / MotoTRBO (Optional software key required) EDACS ProVoice (Optional software key required) NXDN (Optional software key required) |
| Channels / memory management | Enhanced dynamic |
| Power supply | 11-15 VDC (Male 3-pin jack or male barrel jack, center positive) |
| Current drain / power consumption | 350-700 mA |
| Antenna impedance / connector | 50 ohm / BNC |
| Dimensions (W*H*D) | 180*72*160 mm (7.09*2.84*6.3") |
| Weight | 1.4 Kg (3.09 lb) |
| Other features | Customizable 3.5" color display. Close call. USA & Canada data base. CTCSS/PL. DCS. Backlit keypad. Micro-USB jack. S.A.M.E. weather alert. Recording/playback. Trunktracker X. Tracks DMR Tier III, Hytera XPT, NXDN 4800/9600, Motorola, EDACS, APCO25, X2-TDMA and LTR. PC programming and control. GPS. Micro-SD card slot and much more. NB! Some trunking features are optional. |
RECEIVER SECTION
| Receiver system | True I/Q SDR |
|---|---|
| Sensitivity | — |
| Squelch sensitivity | — |
| Noise figure | — |
| Selectivity | — |
| Image rejection | — |
| AF output power / speaker | 3 W at ?% distortion / 8 ohm |
| External speaker connector | TS «Minijack» (3.5 mm), 8 ohm |
MISCELLANEOUS
| Manufactured | Vietnam, 2019-202x |
|---|---|
| Additional info | — |
