SDS-200E
Источник:
GENERAL
| Type | HF/VHF/UHF receiver/scanner |
|---|---|
| Frequency range | Europe and Australia 25-512 / 806-960 / 1240-1300 MHz |
| Tuning steps | 5 / 6.25 / 7.5 / 8.33 / 10 / 12.5 / 15 / 20 / 25 / 50 / 100 KHz |
| Frequency stability | — |
| Mode | Analog AM / FM / NFM / FMB / WFM DV/Digital APCO P25 I/II DMR / MotoTRBO dPMR (Europe only) EDACS ProVoice NXDN NB! Some DV modes may require an optional software key in Australia The European version comes with all keys preinstalled |
| Channels / memory management | Enhanced dynamic @ more than 60 channels per second |
| Power supply | 11-16.6 VDC (Male 3-pin jack or male barrel jack, center positive) |
| Current drain / power consumption | 350-800 mA |
| Antenna impedance / connector | 50 ohm / BNC |
| Dimensions (W*H*D) | 180*72*160 mm (7.09*2.84*6.3") |
| Weight | 1.4 Kg (3.09 lb) |
| Other features | Customizable 3.5" color display. Close call RF capture. CTCSS/PL and DCS. Backlit keypad. Micro-USB jack. Recording/playback. Trunktracker X: Tracks DMR Tier III, Hytera XPT, NXDN 4800/9600, Motorola, EDACS, APCO25, X2-TDMA and LTR. PC programming and control. GPS. Micro-SD card slot and much more. |
RECEIVER SECTION
| Receiver system | True I/Q SDR |
|---|---|
| Sensitivity | AM (Nominal @ 12 dB SINAD) 25.005 MHz: 0.7 uV 118.800 MHz: 0.7 uV 127.175 MHz: 0.7 uV 135.500 MHz: 0.6 uV 225.050 MHz: 0.7 uV 272.950 MHz: 0.7 uV 315.050 MHz: 0.7 uV 325.050 MHz: 0.5 uV FM (Nominal @ 12 dB SINAD) 72.515 MHz: 0.25 uV NFM (Nominal @ 12 dB SINAD) 40.840 MHz: 0.35 uV 53.980 MHz: 0.3 uV 138.150 MHz: 0.6 uV 161.985 MHz: 0.35 uV 173.225 MHz: 0.35 uV 216.020 MHz: 0.35 uV 406.875 MHz: 0.35 uV 511.9125 MHz: 0.35 uV 806.100 MHz: 0.45 uV 857.150 MHz: 0.4 uV 954.9125 MHz: 0.5 uV 1299.925 MHz: 1 uV WFM (Nominal @ 12 dB SINAD) 54.050 MHz: 0.5 uV 197.450 MHz: 0.6 uV FMB (Nominal @ 12 dB SINAD) 107.500 MHz: 0.8 uV Close call (Nominal, no modulation) -57 to -52 dBm (Depending on band) |
| Squelch sensitivity | AM: 0.3 uV (Nominal threshold) FM/NFM: 0.2 uV (Nominal threshold) WFM/FMB: 0.8 uV (Nominal threshold) |
| Noise figure | — |
| Selectivity | — |
| Image rejection | — |
| AF output power / speaker | 3 W at ?% distortion / 8 ohm |
| External speaker connector | TS «Minijack» (3.5 mm), 8 ohm |
MISCELLANEOUS
| Manufactured | Vietnam, 2019-202x |
|---|---|
| Additional info | New price, march 2025 in Sweden: SEK 10995:- |
