G8 Traveler II
Источник:
GENERAL
| Type | HF/VHF receiver/scanner |
|---|---|
| Frequency range | LW/MW (9/10 KHz steps on MW) 3.15-3.45 MHz 3.85-4.05 MHz 4.7-5.1 MHz 5.7-6.3 MHz 7.08-7.6 MHz 9.2-10 MHz 11.45-12.2 MHz 13.5-13.9 MHz 15.0-15.9 MHz 17.45-17.9 MHz 18.85-19.2 MHz 21.43-21.95 MHz 87.5-108 MHz (64-108 MHz capable) |
| Tuning steps | — |
| Frequency stability | — |
| Mode | AM / WFM Stereo |
| Channels / memory management | 500 regular with ATS (Auto Tuning Store) |
| Power supply | 3.6-4.5 VDC (Three LR6 / AA batteries) or 6 VDC external |
| Current drain / power consumption | — |
| Antenna impedance / connector | — / Internal telescopic whip and ferrite bar |
| Dimensions (W*H*D) | 136*87*26 mm (5.35*3.42*1.02") |
| Weight | 201 g (7.09 oz) |
| Other features | Clock. Sleep timer. Alarm. Headphone jack. |
RECEIVER SECTION
| Receiver system | ? conversion superheterodyne |
|---|---|
| Sensitivity | — |
| Selectivity | — |
| Image rejection | — |
| AF output power / speaker | ? mW at ?% distortion /? ohm |
| External speaker connector | — |
MISCELLANEOUS
| Manufactured | 2009-201x (Discontinued) |
|---|---|
| Additional info | — |
| - | - |
