MB1
Источник:
GENERAL
| Type | Amateur HF/VHF SDR transceiver |
|---|---|
| Frequency range | TX: 10-160 m + WARC / 6 m / 2 m RX: 0.09-65 / 95-148 MHz |
| Tuning steps | Depending on software |
| Frequency stability | ±0.5 ppm @ 0 to +50°C (32 to 122°F) |
| Mode | AM / FM / NFM / SSB / CW and more (Depending on software) |
| Channels / memory management | Depending on software |
| Repeater shift / offset | Depending on software |
| Power supply | Mains: 100-240 VAC (3-pin IEC C14 connector) |
| Current drain / power consumption | RX:? VATX: Max? VA |
| Antenna impedance / connector | 50 ohm / Four SO-239 and two N-jacks |
| Dimensions (W*H*D) | 320*140*250 mm (12.6*5.5*9.8") |
| Weight | 10 Kg (22.1 lb) |
| Other features | LAN/WLAN connectivity. Built-in computer with Core i5 CPU. Many possibilities limited only by fantasy |
RECEIVER SECTION
| Receiver system | Direct Down Conversion |
|---|---|
| Sensitivity | — |
| Selectivity | — |
| Image rejection | — |
| AF output power / speaker | ? W at ?% distortion /? ohm |
| External speaker connector | — |
TRANSMITTER SECTION
| RF output power | Max PWR HF m:100 W 6 m:100 W 2 m:50 W |
|---|---|
| HF m | 100 W |
| 6 m | 100 W |
| 2 m | 50 W |
| Modulation system | — |
| Max FM deviation (Factory set) | Depending on software |
| Spurious emissions | Better than -? dB |
| Microphone impedance / connector | ? ohm / ?-pin (Modular) |
| Microphone input level | — |
MISCELLANEOUS
| Manufactured | Taiwan (Designed in Russia), 2015-20xx |
|---|---|
| Additional info | — |
| ? | Internal ATU unit (HF) |
