Flex-6700R
Источник:
GENERAL
| Type | HF/VHF receiver |
|---|---|
| Frequency range | 0.03-72 / 135-165 MHz |
| Tuning steps | Depending on software. 1 Hz resolution |
| Frequency stability | OCXO: 0.02 ppm @ 0 to 50°C (32 to 122°F) |
| Mode | AM / Sync-AM / FM / NFM / DFM / SSB / CW / RTTY |
| Channels / memory management | Depending on software |
| Power supply | Mains: 100-240 VAC (3-pin IEC C14 connector) |
| Current drain / power consumption | 5 W (Standby)50 W (Operational) |
| Antenna impedance / connector | 50 ohm / Two SO-239 and two BNC |
| Dimensions (W*H*D) | 330*102*305 mm (13*4*12") |
| Weight | 4.5 Kg (10 lb) |
| Other features | Two USB ports. Ethernet port. Max panadapter width: 14 MHz. Transverter output. |
RECEIVER SECTION
| Receiver system | Direct digital sampling |
|---|---|
| Sensitivity | — |
| Selectivity | — |
| Image rejection | Better than 100 dB |
| AF output power / speaker | ? W at ?% distortion /? ohm |
| External speaker connector | 600 ohm stereo |
MISCELLANEOUS
| Manufactured | 201x-20xx |
|---|---|
| Additional info | — |
