SR-750
Источник:
GENERAL
| Type | Amateur HF transceiver |
|---|---|
| Frequency range | TX: 10-80 m RX: 10-80 m |
| Tuning steps | Analog / continuous |
| Frequency stability | ±? ppm |
| Mode | SSB / CW |
| Channels / memory management | — |
| Repeater shift / offset | No |
| Power supply | Separate PSU (PS-750-AC) |
| Current drain / power consumption | RX:? mATX: Max? A |
| Antenna impedance / connector | 50 ohm / ? |
| Dimensions (W*H*D) | 380*165*250 mm (?") |
| Weight | ? Kg (? lb) |
| Other features | NB. RIT. VOX. |
RECEIVER SECTION
| Receiver system | ? conversion superheterodyne |
|---|---|
| Sensitivity | — |
| Selectivity | — |
| Image rejection | — |
| AF output power / speaker | ? W at ?% distortion /? ohm |
| External speaker connector | — |
TRANSMITTER SECTION
| RF output power | Pwr SSB (PEP):750 W (Input) CW:250 W (Input) |
|---|
SSB (PEP)
| CW | 250 W (Input) |
|---|---|
| Modulation system | — |
| Max FM deviation (Factory set) | No FM |
| Spurious emissions | Better than -? dB |
| Microphone impedance / connector | ? ohm / ?-pin |
| Microphone input level | — |
MISCELLANEOUS
| Manufactured | USA, 1965-196x (Discontinued) |
|---|---|
| Additional info | New price 1965 in the US: $695.00 (Without PSU) |
| - | - |
