0080
Источник:
GENERAL
| Type | HF/VHF/UHF receiver/scanner |
|---|---|
| Frequency range | 25-520 / 760-1300 MHz |
| Tuning steps | 5 / 12.5 / 50 KHz |
| Frequency stability | — |
| Mode | AM / FM / WFM |
| Channels / memory management | 400 regular in 10 banks @ 8 or 16 channels per second 10 monitor 1 priority RAM storage with 9 V battery backup |
| Power supply | Mains: 220-240 VAC (Fixed power cord)or 12 VDC (Male barrel jack, center positive) |
| Current drain / power consumption | — |
| Antenna impedance / connector | 50 ohm / BNC |
| Dimensions (W*H*D) | 220*76*205 mm (8.7*3*8.3") |
| Weight | 2.2 Kg (4.85 lb) |
| Other features | 10 dB attenuator. Sound squelch. Dimmer. Tape/audio out jack. |
RECEIVER SECTION
| Receiver system | Triple conversion superheterodyne 1st IF:? MHz 2nd IF:? MHz 3rd IF:? KHz |
|---|---|
| Sensitivity | AM, 20 dB S/N 25-520 MHz: 2 uV 760-1100 MHz: 2 uV 1100-1300 MHz: 10 uV FM, 20 dB S/N 25-520 MHz: 0.5 uV 760-1100 MHz: 0.5 uV 1100-1300 MHz: 3 uV WFM, 30 dB S/N 25-520 MHz: 3 uV 760-1100 MHz: 3 uV 1100-1300 MHz: 10 uV |
| Squelch sensitivity | — |
| Noise figure | — |
| Selectivity | — |
| Image rejection | — |
| AF output power / speaker | 1.3 W at ?% distortion / 8 ohm |
| External speaker connector | TS «Minijack» (3.5 mm) |
MISCELLANEOUS
| Manufactured | Japan, 1990-199x (Discontinued) |
|---|---|
| Additional info | This is basically a rebadged Realistic Pro-2005 New price 1991 in Sweden: SEK 3620:- |
| - | - |
