RT-750V
Источник:
GENERAL
| Type | HF/VHF/UHF receiver/scanner |
|---|---|
| Frequency range | 0.1-1300 MHz |
| Tuning steps | 5 / 6.25 / 9 / 10 / 12.5 / 20 / 25 / 50 / 100 / 125 KHz |
| Frequency stability | — |
| Mode | AM / FM / WFM |
| Channels / memory management | 1200 regular 10 priority |
| Power supply | 6 VDC (Four LR6 / AA batteries)or 12 VDC external (Male barrel jack, center positive) |
| Current drain / power consumption | — |
| Antenna impedance / connector | 50 ohm / BNC |
| Dimensions (W*H*D) | 68*150*39 mm (2.68*5.91*1.54") |
| Weight | 210 g (7.41 oz), without batteries |
| Other features | Attenuator. Speech inversion descrambler. Voice guide. |
RECEIVER SECTION
| Receiver system | ? conversion superheterodyne |
|---|---|
| Sensitivity | AM: 1 uV (10 dB S/N) FM: 1.5 uV (12 dB SINAD) WFM:? uV |
| Squelch sensitivity | — |
| Noise figure | — |
| Selectivity | — |
| Image rejection | — |
| AF output power / speaker | ? mW at ?% distortion /? ohm |
| External speaker connector | TS «Minijack» (3.5 mm) |
MISCELLANEOUS
| Manufactured | Japan, 20xx-20xx |
|---|---|
| Additional info | — |
| - | - |
