Pro 2004
Источник:
GENERAL
| Type | HF/VHF/UHF receiver/scanner |
|---|---|
| Frequency range | USA 25-520 / 760-1300 MHz Voluntarily cellular blocked by RadioShack but it could easily be restored. |
| Tuning steps | 5 / 12.5 / 30 / 50 KHz |
| Frequency stability | — |
| Mode | AM / FM / WFM |
| Channels / memory management | 300 regular in 10 banks @ 16 or 8 channels per second 10 temporary in 1 bank 10 search ranges @ 16 or 8 steps per second 1 priority, freely selectable RAM storage with a 9 V battery backup |
| Power supply | Mains: 120 VAC (Fixed power cord)or 13.8 VDC (Male barrel jack, center positive) |
| Current drain / power consumption | Less than 870 mA @ 13.8 VDC |
| Antenna impedance / connector | 50 ohm / BNC |
| Dimensions (W*H*D) | 275*75*230 mm (10.82*2.95*9.05") |
| Weight | 3.2 Kg (7 lb) |
| Other features | Sound squelch. Tape out jack. 10 dB attenuator. Dimmer. |
RECEIVER SECTION
| Receiver system | Triple conversion superheterodyne 1st IF: 607.505-611.5 MHz 2nd IF: 48.5 MHz 3rd IF: 455 KHz (AM/FM) — 10.7 MHz (WFM) |
|---|---|
| Sensitivity | AM (20 dB S/N @ 60% modulation) 25-520 MHz: 2 uV 760-1100 MHz: 2 uV 1100-1300 MHz: 3 uV FM (20 dB S/N @ 3 KHz deviation) 25-520 MHz: 0.5 uV 760-1100 MHz: 0.5 uV 1100-1300 MHz: 3 uV WFM (30 dB S/N @ 22.5 KHz deviation) 25-520 MHz: 3 uV 760-1100 MHz: 3 uV 1100-1300 MHz: 10 uV |
| Squelch sensitivity | AM/FM 25-1100 MHz: 0.5 uV (Threshold) 1100-1300 MHz: 3 uV (Threshold) WFM 25-1100 MHz: 3 uV (Threshold) 1100-1300 MHz: 10 uV (Threshold) |
| Noise figure | — |
| Selectivity | AM/FM 18 KHz (-6 dB)30 KHz (-50 dB) WFM 300 KHz (-6 dB)600 KHz (-50 dB) |
| Image rejection | — |
| AF output power / speaker | 1.8 W at ?% distortion / 8 ohm |
| External speaker connector | TS «Minijack» (3.5 mm) |
MISCELLANEOUS
| Manufactured | Japan (By GRE), 1986-1988 (Discontinued) |
|---|---|
| Additional info | FCC ID: AAO9ZA20-119 New price 1987 in the US: $399.95 New price 1988 in the US: $419.95 |
| - | - |
