D-100
Источник:
GENERAL
| Type | VHF/UHF receiver/scanner |
|---|---|
| Frequency range | 30-50 / 144-174 / 440-512 MHz |
| Tuning steps | — |
| Frequency stability | — |
| Mode | FM |
| Channels / memory management | 10 regular 1 priority CMOS memory with backup battery |
| Power supply | Mains: 117 VAC (2-pin connector) |
| Current drain / power consumption | — |
| Antenna impedance / connector | 50-75 ohm / DIN41585 (Motorola)or telescopic whip |
| Dimensions (W*H*D) | 267*76*178 mm (10.5*3*7") |
| Weight | ? Kg (? lb) |
| Other features | Dimmer. |
RECEIVER SECTION
| Receiver system | Double conversion superheterodyne |
|---|---|
| Sensitivity | — |
| Selectivity | — |
| Image rejection | — |
| AF output power / speaker | ? W at ?% distortion /? ohm |
| External speaker connector | 3.5 mm |
MISCELLANEOUS
| Manufactured | 19xx-19xx (Discontinued) |
|---|---|
| Additional info | — |
| - | - |
