X108
Источник:
GENERAL
| Type | Amateur HF transceiver |
|---|---|
| Frequency range | TX: 10-160 m + WARC RX: 0.5-30 MHz |
| Tuning steps | — |
| Frequency stability | ±? ppm |
| Mode | AM / SSB / CW |
| Channels / memory management | 32 regular |
| Repeater shift / offset | No |
| Power supply | 12.5-14.5 VDC |
| Current drain / power consumption | RX: Max 750 mATX: Max 7 A |
| Antenna impedance / connector | 50 ohm / SO-239 |
| Dimensions (W*H*D) | 120*45*180 mm (4.75*1.75*7.06") |
| Weight | 885 g (1.95 lb) |
| Other features | USB connector. Built-in keyer. |
RECEIVER SECTION
| Receiver system | Single conversion superheterodyne IF:? KHz |
|---|---|
| Sensitivity | 0.2 uV (No reference) |
| Selectivity | SSB 2.4 KHz (-6 dB) CW 500 Hz (-6 dB) |
| Image rejection | — |
| AF output power / speaker | ? W at ?% distortion /? ohm |
| External speaker connector | — |
TRANSMITTER SECTION
| RF output power | Pwr AM:1-20 W SSB (PEP):1-20 W CW:1-20 W |
|---|---|
| AM | 1-20 W |
SSB (PEP)
| CW | 1-20 W |
|---|---|
| Modulation system | — |
| Max FM deviation (Factory set) | No FM |
| Spurious emissions | Better than -40 dBc |
| Microphone impedance / connector | ? ohm / 8-pin modular |
| Microphone input level | — |
MISCELLANEOUS
| Manufactured | China, 2014-20xx (Discontinued) |
|---|---|
| Additional info | New price 2014 in the US: $595.00. Also available as DeLuxe version with all three options below included for the price of $695.00 |
