MVT-3100
Источник:
GENERAL
| Type | VHF/UHF receiver/scanner |
|---|---|
| Frequency range | 143-162.025 / 347.7125-452 / 830-904.9875 MHz |
| Tuning steps | 10 / 12.5 KHz |
| Frequency stability | — |
| Mode | FM |
| Channels / memory management | 100 regular @ 30 channels per second 1 priority 10 search bands 100 pass |
| Power supply | 4.8-6 VDC (Four R6 / AA alkaline or NiCd batteries)or 12 VDC external |
| Current drain / power consumption | 65-140 mA |
| Antenna impedance / connector | 50 ohm / BNC |
| Dimensions (W*H*D) | 59*147*38 mm (2.32*5.79*1.5") |
| Weight | 280 g (9.88 oz) |
| Other features | Backlit display. |
RECEIVER SECTION
| Receiver system | Triple conversion superheterodyne 1st IF: 285 MHz 2nd IF: 45 MHz 3rd IF: 455 KHz |
|---|---|
| Sensitivity | 0.25 uV (12 dB SINAD) |
| Selectivity | — |
| Image rejection | — |
| AF output power / speaker | 100 mW at 10% distortion / 8 ohm |
| External speaker connector | 3.5 mm |
MISCELLANEOUS
| Manufactured | Japan, 1993-199x (Discontinued) |
|---|---|
| Additional info | New price, december 1993 in the UK: £199.00 |
| - | - |
