MS-1000
Источник:
GENERAL
| Type | HF/VHF/UHF receiver/scanner |
|---|---|
| Frequency range | 0.5-600 / 800-1300 MHz |
| Tuning steps | 5 to 995 KHz in any multiple of 5 or 12.5 KHz |
| Frequency stability | — |
| Mode | AM / FM / WFM |
| Channels / memory management | 1000 regular in 10 banks @ 20 channels per second 1 priority 1000 search lockout EEPROM storage |
| Power supply | 12.6 V (Barrel connector, center positive) |
| Current drain / power consumption | 180 mA |
| Antenna impedance / connector | 50 ohm / BNC |
| Dimensions (W*H*D) | 120*50*203 mm (4.72*1.97*7.99") |
| Weight | 750 g (1.65 lb) |
| Other features | 10 dB attenuator. AF scan. Tape and remote jacks. |
RECEIVER SECTION
| Receiver system | ? conversion superheterodyne |
|---|---|
| Sensitivity | AM: 10 uV (20 dBQ) @ 0.5-2 MHz AM: 0.7-1 uV (10 dB S/N) FM: 0.5-1 uV (12 dB SINAD) WFM: 1 uV (20 dB S/N) |
| Selectivity | — |
| Image rejection | — |
| AF output power / speaker | 500 mW at ?% distortion / 8 ohm |
| External speaker connector | 3.5 mm, 8 ohm |
MISCELLANEOUS
| Manufactured | Japan, 19xx-19xx (Discontinued) |
|---|---|
| Additional info | — |
| - | - |
