TS-93X MkII
Источник:
GENERAL
| Type | Amateur HF transceiver |
|---|---|
| Frequency range | Australia TX: 10-160 m + WARC RX: 0.15-30 MHz |
| Tuning steps | 10 Hz |
| Frequency stability | Within ±200 Hz during the first hour after power on. Within ±30 Hz any 30 minute period thereafter. |
| Mode | AM / SSB / CW / FSK |
| Channels / memory management | 8 regular RAM storage with battery backup (Three LR6 / AA batteries) |
| Repeater shift / offset | No |
| Power supply | Mains: 120 / 220 / 240 VAC |
| Current drain / power consumption | RX: Max 80 WTX: Max 510 W |
| Antenna impedance / connector | 50 ohm / SO-239 |
| Dimensions (W*H*D) | 374*141*350 mm (14.72*5.55*13.78") |
| Weight | 16.8 Kg (37 lb), without options |
| Other features | Two noise blankers. SSB slope tuning. VOX. IF output. Transverter port. Phone patch port. |
RECEIVER SECTION
| Receiver system | Quadruple conversion superheterodyne 1st IF: 44.93 MHz 2nd IF: 8.83 MHz 3rd IF: 455 KHz 4th IF: 100 KHz |
|---|---|
| Sensitivity | AM (10 dB S/N) 0.15-0.5 MHz: 10 uV 0.5-1.8 MHz: 32 uV 1.8-30 MHz: 2 uV SSB/CW/FSK (10 dB S/N) 0.15-0.5 MHz: 1 uV 0.5-1.8 MHz: 4 uV 1.8-30 MHz: 0.25 uV |
| Selectivity | AM(W), without optional filter 6 KHz (-6 dB), 18 KHz (-60 dB) AM(N) 2.7 KHz (-6 dB), 4 KHz (-60 dB) SSB/CW/FSK, without optional filters 2.7 KHz (-6 dB), 4 KHz (-60 dB) |
| Image rejection | 80 dB |
| AF output power / speaker | 1.5 W at 10% distortion / 8 ohm |
| External speaker connector | 3.5 mm |
TRANSMITTER SECTION
| RF output power | AM:~25 W (80 W input) SSB (PEP):~125 W (250 W input) CW (DC):~125 W (250 W input) FSK:~125 W (250 W input) |
|---|---|
| AM | ~25 W (80 W input) |
FSK
| Modulation system | AM: Low level (IF stage)SSB: Balanced |
|---|---|
| Max FM deviation (Factory set) | No FM |
| Spurious emissions | Better than -? dB |
| Microphone impedance / connector | 500 ohm to 50 Kohms / 8-pin (Metal locking ring connector) |
| Microphone input level | — |
MISCELLANEOUS
| Manufactured | Japan, 1982-198x (Discontinued) |
|---|---|
| Additional info | This is the australian version of TS-930S. The performance and features are identical and the only difference is that out-of-amateur band transmission is not possible. This was to comply with new government regulations at the time. |
| AT-930 HC-10 HS-4 HS-5 HS-6 MC-60A PC-1A SM-220 SO-1 SP-930 TL-922 YG-455C-1 YG-455CN-1 YK-88A-1 YK-88C-1 | Internal automatic antenna tuner. 10-80 m Digital world clock Headphones Headphones Headphones Deluxe desk microphone with up/down switches Hybrid phone patch Station monitor High stability crystal unit (TCXO), 20 MHz External speaker Linear amplifier CW filter, 500 Hz. IF: 455 KHz CW filter, 250 Hz. IF: 455 KHz AM filter, 6 KHz. IF: 8.83 MHz CW filter, 500 Hz. IF: 8.83 MHz |
